GEARCUT M46

The development of this product aimed at tooth turning, there are too harsh conditions, when using imported process oil lubricant is carried out high cost, when using domestic oil products there is odour, smoke, oil life and other problems, so we studied and researched the excellent in performance coolant with economic characteristics.



This oil is suitable for high-speed and heavy machining processes of metals with high hardness and machining difficulty, in particular, alloy steel, cast iron and other materials and higher precision requirements of gear machining process, such as milling, tooth turning and thread machining are recommended.


Product characteristics

Outstanding profitability

product name

GEARCUT M46

Kinematic viscosity , mm2/s, 40 ℃

100 ℃



34.57

5.795

Kinematic viscosity

109

Alkali, mgkoh/g

0.24

Acidity, mgkoh/g

0.14

Corrosion of the copper leaflet100 ℃,  class

4c

Open flash point , ℃

200

Tilt point , ℃

-9

Bubble -resistance test , ml/ml

24 ℃ 93.5 ℃

Last24 ℃



150/0

290/0

300/0

Cleaning , mgkoh/g

15

Four Extreme pressure balls (3142)

  Maximum load without bite pb , n

882.6

Four Extreme pressure balls (3142) PD , n sinter

3922.7

The diameter of the spot during milling (392n) , mm

0.47


Technical indicators

Points

GEARCUT M46

Kinematic viscosity , mm2/s,

38.8

Alkali, mgkoh/g

0.23

Acidity, mgkoh/g

0.44

Corrosion of a copper leaf, class

4c

Color, level

3.0

Open flash point , ℃

198

Tilt point , ℃

-9

Bubble -resistance test , ml/ml

24 ℃ 93.5 ℃

  The last 24 ℃

310/0

480/10

500/10

Cleaning , mgkoh/g

54

Four Extreme pressure balls (3142) maximum load without bite PB , KG

 77

Four Extreme Pressure Balls (3142) PD , KG sintering load

800

The efficiency of torque during drilling (compared to Fuchs MSN) ,%

100


Functions

▪ Excellent smoke resistance, low volatility, provides an optimal working environment, the most economical losses

▪ Good cooling lubricant, which extends the life of the tool so that the surface quality of the part reaches the optimal state

▪ The best thermal conductivity, providing a higher supply speed and cutting speed during processing

▪ Various tape filtration systems for centralized and autonomous lubrication systems and machines

▪ Not suitable for processing non -ferrous metals

▪ When using, you do not need to dilute, direct use

▪ excellent properties of extreme pressure, lubrication, cooling, effective removal of friction heat to avoid oil fog, smoke and deformation of parts caused by this

▪ Without chlorine, environmentally friendly.

▪ Low smoke, low volatility, low smell

▪ Effective increase in processing efficiency, reducing tool wear

Applications

▪ The development of this product is mainly aimed at the process of forming the gear in the process of pumping teeth, at the development of gear processing, is a special coolant.

▪ Suitable for large processing volumes, lower heavy load speeds and has certain requirements for processing accuracy. More typical applications include multi -axial automatic machines, semi -automatic machines and combined machines.

▪ This product is especially suitable for turning gear tooth in production.
