Chemical composition:
Monol initiated propylene oxide/ethylene oxide copolymer
Product characteristics
| Properties | |||||||
| Physical form | Colorless to slightly yellow liquid | ||||||
| Physical data | Characteristic | Unit | HY105 | ||||
| Viscosity (ASTM D445) at 40 °C at 100 °C | mm2/s | 52 11 | |||||
| Viscosity index (ASTM D2270) | 212 | ||||||
| Water content (ASTM E203) | % | < 0.25 | |||||
| Density; 20 °C (ASTM D1298) | g/cm3 | 1.033 | |||||
| Flash point coc (ASTM D92) | °C | 220 | |||||
| Pour point (ASTM D97) | °C | – 53 | |||||
| Ash content (ASTM D482) | % | < 0.01 | |||||
| Refractive index, 20 °C | 1.46 | ||||||
| Surface tension, 20 °C | mN/m | 33 – 38 | |||||
| Vapour pressure, 20 °C | mmHg | < 0.001 | |||||
| Specific heat capacity | kJ/kg | 1.95 | |||||
| Equilibrium water content at 65 % relative humidity, 21 – 28 °C | 1.5 – 2.5 | ||||||
| Quality control | The above-listed data represent average values at the time of going to press of this Technical Information. They are intended as a guide to facilitate hand- ling and cannot be regarded as specified data. Specified product data are issued as a separate product specification . | ||||||
| Seal compatibility | The elastomer performance of HY105 with various seal types are shown below. | ||||||
| Test conditions: 120 hours at 70 °C | |||||||
| Elastomer | Linear swell (%) | Change of hardness | |||||
| Natural rubber Styrene butadiene (SBR) Nitrile Butadiene (NBR) Isobutene isoprene (IIR) 1 Isobutene isoprene (IIR) 2 Chloroprene (CR) Silicone (Q) | 0.6 1.2 2 0 – 1.4 7.5 0.2 | – 4 – 5 – 4 – 1 2 – 17 – 2 | |||||
| Solubility data | Materials | HY105 | |||||
| Chlorinated solvents e. g. ethylene dichloride | soluble | ||||||
| C1-C14 alcohols, higher glycols e. g. methanol, isopropanol, hexanol … | soluble | ||||||
| Toluene, benzene, cyclohexene, acetone | soluble | ||||||
| saturated hydrocarbons e. g. petrol, kerosene, petroleum ether, cyclohexane | insoluble | ||||||
| Ethers/glycol ethers e. g. ethyl glycol ether, butyl ether diglycol ether, butyl | soluble soluble | ||||||
| Glycols e. g. MPG, 1,3-butanediol | soluble | ||||||
| MEG, Glycerol | insoluble | ||||||
| Castor oil, coconut oil, linseed oil, palm oil, pine oil and tall oil | soluble | ||||||
| Petroleum oil, lanolin oil | insoluble | ||||||
| Corn oil, cottonseed oil, neatsfoot oil, rapeseed oil | soluble/partly soluble when hot | ||||||
| Methyl- & butyl-methacrylate polymers, Dammar, polystyrene | partly soluble | ||||||
| Polyvinyl ethyl ether, ester gum, wood rosin | soluble soluble | ||||||
Applications
HY 103 is a high performance water soluble polyalkylene glycol basestock with a viscosity of 52 mm2/s at 40 °C. HY 103 finds extensive application when manufacturing and formulating various water soluble lubricants for example:
• Gear, bearing and calender lubricants
• Compressor lubricants
• Metal working fluids
Storage
▪ HY 103 should be kept tightly sealed in a dry place in its tightly sealed original packaging. Storerooms must not be overheated.
▪ HY103 is hygroscopic with the result of absorbing moisture very quickly. Care needs to be taken to exclude moisture. Drums must be resealed each time they are opened.
▪ HY103 must be blanketed with nitrogen if stored in heated tanks (at < 60 °C) to prevent from coming into contact with air. Constant, gentle stirring helps to prevent discoloration as a result of prolonged contact with electrical elements or external heating coils.
Shelf life:Provided it is stored properly and the drums are kept tightly sealed, HY103 has a shelf life of five years in its original packaging.
