Chemical composition:
Diol started random propylene oxide/ethylene oxide copolymer
Product characteristics
| Properties | |||
| Physical form | Colorless to slightly yellow liquid | ||
| Physical data | Characteristic | Unit | HY113 |
| Viscosity (ASTM D445) at 40 °C at 100 °C | mm2/s | 2025 300 | |
| Viscosity index (ASTM D2270) | 335 | ||
| Water content (ASTM E203) | % | < 0.25 | |
| Density, 20 °C (ASTM D1298) | g/cm3 | 1.097 | |
| Flash point coc (ASTM D92) | °C | 252 | |
| Pour point (ASTM D97) | °C | 6 | |
| Ash content (ASTM D482) | % | < 0.1 | |
| Refractive index, 20 °C | 1.466 | ||
| Vapor pressure, 20 °C | mmHg | < 0.001 | |
| Specific heat capacity | kJ/kg | 1.95 | |
| Equilibrium water content at 65 % relative humidity, 21 – 28 °C | 4 – 6 | ||
Quality control
The above-listed data represent average values at the time of going to press of this Technical Information. They are intended as a guide to facilitate handling and cannot be regarded as specified data. Specified product data are issued as a separate product specification.
Applications
▪ HY110 is a high performance water soluble polyalkylene glycol lubricant basefluid with a viscosity of 2025 mm2/s at 40 °C.
▪ HY110 shows high thermal and high shear stability. The high viscosity and low volatility of HY110 makes it very suitable for high temperature lubrication.
▪ HY110 find extensive application in quenchants, metalworking fluids and water based hydraulic fluids formulations, demonstrating excellent shear stability and providing good lubricity to the finished fluids.
▪ HY110 is soluble in water at temperatures below 75 °C.
Storage
▪ HY110 should be kept tightly sealed in a dry place in its tightly sealed original packaging. Storerooms must not be overheated.
▪ HY110 is hygroscopic with the result of absorbing moisture very quickly. Care needs to be taken to exclude moisture. Drums must be resealed each time they are opened.
▪ HY110 must be blanketed with nitrogen if stored in heated tanks (at 50 – 60 °C) to prevent from coming into contact with air. Constant, gentle stirring helps to prevent discoloration as a result of prolonged contact with electrical elements or external heating coils.
Shelf life:Provided it is stored properly and the drums are kept tightly sealed, HY110 has a shelf life of five years in its original packaging.
